2D LiDAR sensors
LMS1000

Lightning-fast measurement – in record time!

Your Benefits

  • The very high scan rate makes the collection of large data volumes and detection of quick objects possible
  • HDDM+ with multi-echo technology for greater availability when subjected to environmental influences like rain, snow, and dust
  • High flexibility for installation thanks to rotating male/female connectors
  • Integrated field evaluation and measured data output makes it possible to tackle various applications with one sensor
  • Low setup costs: Identical telegram for all 2D LiDAR sensors from SICK
  • Fields that are easy to teach in save time during setup
  • Low maintenance costs thanks to high weather resistance

Overview

Lightning-fast measurement – in record time!

The LMS1000 is SICK’s quickest 2D LiDAR sensor at 150 Hz. Even when the weather is bad, the high speed and exceptional performance ensure that the scanner collects large data quantities and detects even very quick objects. Thanks to the HDDM+ method with multi-echo technology, the scanner is best suited for use outdoors. The combination of high speed and ruggedness makes this scanner the perfect candidate in applications that require fast data acquisition such as in traffic management. The LMS1000 is versatile: With field evaluation and data output in one sensor, it is the ideal solution in a wide range of tasks and rotating male connectors make mounting flexible. User-friendly operation rounds of this exceptional profile.

At a glance
  • Efficient sensor with integrated high-speed evaluation
  • High weather resistance and reliability through HDDM+ with multi-echo technology
  • Field evaluation and measured data in one sensor
  • Easy configuration, with the ability to adapt to a changing environment
  • Convenient and simple diagnostics via web server



Advantages

The LMS1000 2D LiDAR sensor is the ideal solution for indoor and outdoor applications, even under adverse ambient conditions. This outstanding performance can be improved even more with additional digital filters for preparation and optimization of distance values measured by the LMS1000. With the filter, the user can perfectly and efficiently adjust the LMS1000 to the specific requirements of the respective application. SICK offers various filters for this purpose.

The LMS1000 is not bothered by environmental influences such as rain, fog, dust and ambient light.
The innovative HDDM+ technology enables measurement at long distances and is characterized by low noise in the measured value data as well as multi-echo capability.
Discover the advantages of the HDDM+ technology and multi-echo evaluation in the video.

High availability even under unfavorable ambient conditions and very good reliability when detecting objects

Reliably detecting objects at very high speeds is a challenge. This task becomes an even bigger challenge when adverse ambient conditions greatly impair visibility. The LMS1000 is a specialist in exactly these types of situations. With its revolutionary scan rate of 150 Hz, it reacts in no time and, with its combination of field evaluation and measurement data output, the LMS1000 covers various application areas.
The LMS1000 delivers reliable measurement results when protecting indoor and outdoor areas and is well-suited for object protection and access control.
Due to its excellent outdoor capabilities, the LMS1000 is perfect for reliable traffic monitoring at toll stations or road control posts.
If fast pass-through monitoring is required, e.g. where strict safety precautions are necessary, the LMS1000 is the ideal solution thanks to its high scan rate.

The very high scan rate makes the collection of large data volumes and detection of quick objects possible

Strong performance, versatile in use

The large selection of accessory components enables variable adjustment of the LMS1000 to the respective application requirements. This increases flexibility when it comes to application possibilities in your industry, while at the same time reducing storage costs and expenditures for different variants as well as integration. The easy and convenient sensor diagnostics via web server as well as the user-friendly operation round out the exceptional profile of the LMS1000.
Always well protected From simple brackets to mountings for fine adjustment and weather hoods for protection against weather conditions - the right solution for any application.
Always well connected Large selection of cables and power supply units up to connection modules.
No worries about space Rotatable connections also enable flexible mounting, both indoors and outdoors.

High flexibility during installation, convenient parameterization and simple diagnostics via web server

Applications

Technical overview


  • Technical data overview

    Technical data overview

    ApplicationOutdoor
    Measurement principleHDDM+
    Integrated applicationIntegrated field evaluation with flexible fields, Data output
    Aperture angle
    275°
    Angular resolution0.75°
    Working range0.2 m ... 64 m
    Scanning range
    16 m
    30 m
    Amount of evaluated echoes3
    Scanning frequency150 Hz, 4 x 37,5 Hz
    HeatingNo
    Ambient operating temperature–30 °C ... +50 °C
    Ethernet
    Weight1.2 kg
All technical data can be found accompanying the individual product
